Hiab 435K Knuckle Boom Crane – Power Meets Precision

🏗️ Hiab 435K Knuckle Boom Crane – Power Meets Precision

Heavy-Duty Hydraulic Crane | Built for Efficiency, Reach, and Versatile Lifting

🏗️ Crane Overview – Hiab 435K

• Make/Model: Hiab 435K – Top-tier mid-to-heavy class articulated (knuckle boom) crane

• Lifting Capacity: Up to 43,000 kgf/cm (approx. 9,480 lbs at full reach)

• Max Horizontal Reach:

  • Up to 52 ft (16 m) with full hydraulic extensions

  • Optional manual extensions for added length

• Vertical Reach: Approx. 60–65 ft with extended boom (ideal for 3–5 story access)

• Boom Type: Multi-section hydraulic knuckle boom – compact when stowed, extended when you need reach

• Slewing/Rotation: 400°+ hydraulic slewing with high-torque turning

• Boom Movement:

  • Fold/unfold in tight spaces

  • Reach over fences, walls, or barriers with ease

• Stabilizers/Outriggers:

  • Dual hydraulic outriggers with wide stance

  • Optional rear stabilizers for max lift support

  • Auto-leveling and manual override control

🧠 Controls & Safety

• Control System:

  • Standard: Dual side manual controls

  • Optional: HiPro Remote Control System for full wireless operation with precision feathering

• Safety Features:

  • Load Moment Indicator (LMI)

  • Overload Protection System

  • Anti-two-block warning system

  • Emergency stop buttons at both stations

• Ease of Operation: Designed for fast setup, operator visibility, and jobsite safety

🛠️ Ideal Chassis Pairing (If Selling as a Package)

• Mounts easily on 26,000 – 66,000+ GVWR trucks (e.g., Freightliner M2, International 7400, Volvo, Peterbilt)

• Compatible with flatbeds, drywalls, utility bodies, or forestry units

• PTO-driven hydraulic pump or electric/hydraulic configuration

✅ Perfect For:

• Drywall, roofing, or construction material delivery

• Concrete forms, steel placement, or jobsite pallet delivery

• Municipal work (utility poles, transformers, street lights)

• Forestry, landscaping, and precast concrete installation

• Crane rental fleets looking for remote-controlled articulation

🔍 Condition & Specs (for Used Units)

• Year: [Insert year of manufacture]

• Condition: Clean, functional, inspected and ready for install

• Hydraulics: Leak-free, all extensions fully tested

• Remote: Included (if applicable) – new batteries and receiver calibrated

• Title/Docs: Clean ownership and CE/ANSI certification available

💰 Pricing, Install & Delivery

• Pricing: Competitive vs Palfinger, Fassi, and PM cranes in same class

• Installation: We offer mounting + PTO configuration on your truck

• Financing available (OAC)

• Nationwide shipping or install services available

🔧 Why Choose the Hiab 435K?

• World-class knuckle boom design – Durable, smooth, and intuitive

• Compact stow height + long reach = more deliveries per shift

• HiPro control option makes it single-operator friendly

• Backed by Hiab's global parts and service network

• Excellent resale value and brand reputation across industries
